Features:
Thelux LED Highbay light fixtures bring parking area illumination into the 21st century. Our patented optics maximize light distribution and placement with exceptional, low-glare illumination on the intended area, while minimizing light trespass into nearby homes and businesses.
1.Die casting -aluminium housing with corrosion resistant and rust resistant power coated finish. And with IP66 protection, they can work fine in terrible outdoor environments.
2.Adjustable angle bracket, easy to find a suitable mounting angle.
3. High lumen 3030or 5050LED chip of Philips, OSRAM, CREE, BRIDGELUX, and Epistar. No UV or infrared. Higher light efficiency and more stable.
Technical Specifications:
Mod No. | Voltage | Power | Size | Light out | Efficency | CRI | Beam angle | Light Source | Driver | CCT | ||
V | W | mm | lm | lm/W | Ra≥ | ° | type | Chip QTY | Isolate? | PF> | K | |
TSL-HL007/100 | AC85-265V | 100 | dia. 410*H305 | 10000 | 100-120 | 70 | 120 | 3030 | 120 PCS | isolated | 0.9 | 2700-7000 |
TSL-HL007/150 | AC85-265V | 150 | dia. 410*H305 | 15000 | 100-120 | 70 | 120 | 3030 | 180 PCS | isolated | 0.9 | 2700-7000 |
TSL-HL007/200 | AC85-265V | 200 | dia. 450*H313 | 20000 | 100-120 | 70 | 120 | 3030 | 240 PCS | isolated | 0.9 | 2700-7000 |
TSL-HL007/300 | AC85-265V | 300 | dia.500*H325 | 30000 | 100-120 | 70 | 120 | 3030 | 360 PCS | isolated | 0.9 | 2700-7000 |
