Features:
Technical Specifications:
| Mod No. | Voltage | Power | Size | Light out | Efficency | CRI | Beam angle | Light Source | Driver | CCT | ||
| V | W | MM | lm | lm/W | Ra≥ | ° | Type | Chip QTY | Isolate | PF＞ | K | |
| TSL-FL024/200 | AC100-305V | 200 | 425*325*170 | 20000 | 100-120 | 70 | 60 | 2835 | 400 PCS | Isolated | 0.9 | 6000-6500 |
| TSL-FL024/300 | AC100-305V | 300 | 597*325*190 | 30000 | 100-120 | 70 | 60 | 2835 | 602 PCS | Isolated | 0.9 | 6000-6500 |
| TSL-FL024/400 | AC100-305V | 400 | 670*320*200 | 40000 | 100-120 | 70 | 60 | 2835 | 798 PCS | Isolated | 0.9 | 6000-6500 |
| TSL-FL024/500 | AC100-305V | 500 | 820*330*190 | 50000 | 100-120 | 70 | 60 | 2835 | 994 PCS | Isolated | 0.9 | 6000-6500 |
| TSL-FL024/600 | AC100-305V | 600 | 820*330*190 | 60000 | 100-120 | 70 | 60 | 2835 | 1190 PCS | Isolated | 0.9 | 6000-6500 |
| TSL-FL024/800 | AC100-305V | 800 | 820*330*190 | 80000 | 100-120 | 70 | 60 | 2835 | 1596 PCS | Isolated | 0.9 | 6000-6500 |
| TSL-FL024/1000 | AC100-305V | 1000 | 820*330*190 | 100000 | 100-120 | 70 | 60 | 2835 | 1984 PCS | Isolated | 0.9 | 6000-6500 |
